OBS Control Dock Guide - Social Stream Ninja

Quick setup

In Social Stream Ninja, open Global settings and tools → Mechanics.
Enable remote API control of extension. Keep Social Stream Ninja active during the stream.
Copy the Session ID shown in Social Stream Ninja.
In OBS, open Docks → Custom Browser Docks.
Name the dock Social Stream Controls and use this URL:

https://socialstream.ninja/obs-control-dock.html?session=YOUR_SESSION_ID

Select Apply, close the settings window, and place the new dock where you want it in OBS.
Confirm the dock says Connected. If the URL did not include a session, enter it in the dock and select Save & connect.

Open the Control Dock

Which server settings are required?

Setting	For this control dock	Purpose
remote API control of extension	Required	Lets the control dock send commands to the Social Stream app or extension on channel 1.
Enable Dock to use and publish via API server	Not required	Optional direct server transport for the Streaming Chat Dock.
Send chat messages to API server	Not required	Used when an external program needs to receive captured chat on channel 4.
Dock sends its commands to Extension via server	Not required	Used when the Streaming Chat Dock itself must send commands back through the server.

No &server is needed on the control-dock or Credits URLs. The control dock already opens its own WebSocket control connection. OBS's WebSocket Server Settings are unrelated and can remain off.

If you intentionally use direct API transport for dock.html, use the generated Dock link after enabling its server setting, or add &server to that Dock URL. This is optional and does not change how Credits commands work.

Using it with end-of-stream Credits

Before the stream, set Credits Trigger Mode to Background collection. This lets the app collect chatters, members, and donors while the Credits Browser Source is closed.
Add the generated Credits URL to the OBS ending scene using the same Session ID.
At the end of the stream, switch to the ending scene first so the Credits Browser Source is loaded and connected.
Select Start Credits in the OBS control dock.

Load before Start: background collection can work while the Credits page is closed, but Start, Preview, and Test need a connected Credits Browser Source to display anything.

See the Credits Roll Guide for collection modes, filters, and troubleshooting missing names.

What each Credits button does

Button	Result
Start Credits	Runs the real collected list.
Preview	Runs the real list without consuming page-collected entries.
Test Credits	Displays built-in participant, member, and donor examples. It does not prove that real names were collected.
Reset Saved Credits	Clears the saved Background collection for the active Social Stream session.

Other controls and their required pages

Featured Chat: keep the normal Streaming Chat Dock and featured overlay connected on the same session.
Timer: keep the Timer page connected on the same session if it needs to display the timer.
Waitlist & Giveaway: configure the waitlist in Social Stream first; Reset clears the current entries.

The dock reconnects automatically if the API connection drops. A green Connected status only confirms the control connection; the target page still needs to be open when a command displays something.

Direct API examples

The same buttons can be scripted with HTTP GET requests:

https://io.socialstream.ninja/SESSION_ID/creditsStart
https://io.socialstream.ninja/SESSION_ID/creditsPreview
https://io.socialstream.ninja/SESSION_ID/creditsTest
https://io.socialstream.ninja/SESSION_ID/creditsReset

Replace SESSION_ID with the active Social Stream session. See Commands & API or the full API sandbox for more actions.

Troubleshooting

Session needed: use the exact Session ID from Social Stream, without the word session=.
Disconnected: enable remote API control, confirm Social Stream is active, and reopen the dock after changing its URL.
Credits says no source accepted the command: reveal the ending scene, wait for its Browser Source to load, then retry.
Test works but Start is empty: Test uses built-in names. Select Background collection before the stream and confirm normal chat sources are capturing.
Featured Chat button has no visible effect: confirm the Streaming Chat Dock and featured overlay use the same session and are loaded.
